#Configuration

RNEF can be configured through a configuration object that defines various aspects of your project setup.

The most basic configuration would, assuming you only support iOS platform and choose Metro as our bundler, would look like this:

// @ts-check
import { platformIOS } from '@rnef/platform-ios';
import { pluginMetro } from '@rnef/plugin-metro';

/** @type {import('@rnef/config').Config} */
export default {
  bundler: pluginMetro(),
  platforms: {
    ios: platformIOS(),
  },
};

#All Configuration Options

{
  // Optional: Root directory of your project
  root?: string;

  // Optional: React Native version being used
  reactNativeVersion?: string;

  // Optional: Custom path to React Native in node_modules
  reactNativePath?: string;

  // Optional: Custom bundler plugin
  bundler?: PluginType;

  // Optional: Array of plugins
  plugins?: Array<PluginType>;

  // Optional: Platform-specific configurations
  platforms?: Record<string, PlatformType>;

  // Optional: Additional commands
  commands?: Array<Command>;

  // Optional: Configure remote cache provider. Currently supports: 'github-actions' or null
  remoteCacheProvider?: 'github-actions' | null;

  fingerprint?: {
    // Additional source files/directories to include in fingerprint calculation
    extraSources?: string[];

    // Paths to ignore when calculating fingerprints
    ignorePaths?: string[];
  }
}

#Plugins

A plugin is a partially applied function that has access to api object of PluginApi type:

type PluginApi = {
  registerCommand: (command: CommandType) => void;
  getProjectRoot: () => string;
  getReactNativeVersion: () => string;
  getReactNativePath: () => string;
  getPlatforms: () => { [platform: string]: object };
  getRemoteCacheProvider: () => null | undefined | (() => RemoteBuildCache);
  getFingerprintOptions: () => {
    extraSources: string[];
    ignorePaths: string[];
  };
};

The following configuration options accept plugins: plugins, platforms, bundler.

A plugin that registers my-command command outputing a hello world would look like this:

const simplePlugin =
  (pluginConfig: SamplePluginConfig) =>
  (api: PluginApi): PluginOutput => {
    api.registerCommand({
      name: 'my-command',
      description: 'My command description',
      action: async (args) => {
        console.log('hello world');
      },
    });
  };

export default {
  plugins: [simplePlugin()],
};

#Bundler

Bundler is a plugin that registers commands for running a dev server and bundling final JavaScript or Hermes bytecode.

By default, RNEF ships with two bundler: Metro (@rnef/plugin-metro) and Re.Pack (@rnef/plugin-repack).

You can configure the bundler like this:

import { pluginMetro } from '@rnef/plugin-metro';

export default {
  // ...
  bundler: pluginMetro(),
};

#Platforms

Platform is a plugin that registers platform-specific functionality such as commands to build the project and run it on a device or simulator.

By default, RNEF ships with two platforms: iOS (@rnef/platform-ios) and Android (@rnef/platform-android).

You can configure the platform like this:

import { platformIOS } from '@rnef/platform-ios';

export default {
  // ...
  platforms: {
    // config is optional; it translates to `project` config from react-native.config.js file
    ios: platformIOS(config),
  },
};

#Remote Cache Configuration

One of the key features of RNEF is remote build caching to speed up your development workflow. By remote cache we mean native build artifacts (e.g. APK, or IPA binaries), which are discoverable by the user and available for download. Remote cache can live on any static storage provider, such as S3, R2, or GitHub Artifacts. For RNEF to know how and where to access this cache, you'll need to define remoteCacheProvider, which can be either bundled with the framework (such as the one for GitHub Actions) or a custom one that you can provide.

When remoteCacheProvider is set, the CLI will:

1. Look at local cache under .rnef/ directory for builds downloaded from a remote cache.
2. If not found, it will look for a remote build matching your local native project state (a fingerprint).
3. If not found, it will fall back to local build.

Available providers you can use:

• @rnef/provider-github: store artifacts on GitHub Workflow Artifacts
• @rnef/provider-s3: store artifacts on S3 (or Cloudflare R2)

In case you would like to store native build artifacts in a different kind of remote storage, you can implement your own custom provider.

#Uploading artifacts to remote storage

Regardless of remote cache provider set, to download native build artifats from a remote storage, you'll need to upload them first, ideally in a continuous manner. That's why the best place to put the upload logic would be your Continuous Integration server.

RNEF provides out-of-the-box GitHub Actions for:

• callstackincubator/ios: action for iOS compatible with @rnef/provider-github
• callstackincubator/android: action for Android compatible with @rnef/provider-github

For other CI providers you'll need to manage artifacts yourself. We recommend mimicking the GitHub Actions setup on your CI server.

#GitHub Actions provider

If you store your code on GitHub, one of the easiest way to setup remote cache is through @rnef/provider-github and our GitHub Actions, which will manage building, uploading and downloading your native artifacts for iOS and Android.

You can configure it as follows:

import { providerGitHub } from '@rnef/provider-github';

export default {
  // ...
  remoteCacheProvider: providerGitHub({
    owner: 'github_org',
    repository: 'github_repo_name',
    token: 'personal_access_token',
  }),
};

#AWS S3 provider

If you prefer to store native build artifacts on AWS S3 or Cloudflare R2, you can use @rnef/provider-s3. You can configure it as follows.

import { providerS3 } from '@rnef/provider-s3';

export default {
  // ...
  remoteCacheProvider: providerS3({
    bucket: 'your-bucket',
    region: 'your-region',
    accessKeyId: 'access-key',
    secretAccessKey: 'secret-key',
  }),
};

#Cloudflare R2

Thanks to R2 interface being compatible with S3, you can store and retrieve your native build artifacts from Cloudflare R2 storage using S3 provider. Set the endpoint option to point to your account storage.

import { providerS3 } from '@rnef/provider-s3';

export default {
  // ...
  remoteCacheProvider: providerS3({
    endpoint: 'https://${ACCOUNT_ID}.r2.cloudflarestorage.com',
    bucket: 'your-bucket',
    region: 'your-region',
    accessKeyId: 'access-key',
    secretAccessKey: 'secret-key',
  }),
};

#Custom remote cache provider

You can plug in any remote storage by implementing RemoteBuildCache interface. A simplest remote cache provider, that loads artifact from a local directory available on your filesystem, would look like this:

import type { RemoteBuildCache } from '@rnef/tools'; // dev dependency of provider

class DummyLocalCacheProvider implements RemoteBuildCache {
  name = 'dummy';
  // artifactName is provided by RNEF, and will look like this:
  // - rnef-android-release-7af554b93cd696ca95308fdebe3a4484001bb7b4
  // - rnef-ios-simulator-Debug-04c166be56d916367462fc3cb1f067f8ac4c34d4
  // depending on flags passed to the `run:*` commands
  async list({ artifactName }) {
    const url = new URL(`${artifactName}.zip`, import.meta.url);
    return [{ name: artifactName, url }];
  }
  async download({ artifactName }) {
    const artifacts = await this.list({ artifactName });
    const filePath = artifacts[0].url.pathname;
    const fileStream = fs.createReadStream(filePath);
    return new Response(fileStream);
  }
  async delete({ artifactName }: { artifactName: string }) {
    // ...
  }
  async upload({ artifactName }: { artifactName: string }) {
    // ...
  }
}

const pluginDummyLocalCacheProvider = (options) => () =>
  new DummyLocalCacheProvider(options);

Then pass the pluginDummyLocalCacheProvider function called with optional configuration object (in case you need authentication or anything user-specific, such as repository information) as a value of the remoteCacheProvider config key:

export default {
  // ...
  remoteCacheProvider: pluginDummyLocalCacheProvider(options),
};

Once this is set up, when running run:* commands, RNEF will calculate the hash of your native project for said platform, and call the download method to resolve the path to the binary that will be installed on a device.

#Opt-out of remote cache

If you only want to use the CLI without the remote cache, and skip the steps 1. and 2. and a warning that you're not using a remote provider, you can disable this functionality by setting it to null:

export default {
  // ...
  remoteCacheProvider: null,
};

#Fingerprint Configuration

A fingerprint is a representation of your native project in a form of a hash (e.g. 378083de0c6e6bb6caf8fb72df658b0b26fb29ef). It's calculated every time the CLI is run. When a local fingerprint matches the one that's generated on a remote server, we have a match and can download the project for you instead of building it locally.

The fingerprint configuration helps determine when builds should be cached and invalidated in non-standard settings, e.g. when you have git submodules in your project:

export default {
  // ...
  fingerprint: {
    extraSources: ['./git-submodule'],
    ignorePaths: ['./temp'],
  },
};

The fingerprint calculation uses @expo/fingerprint under the hood.
